IPB200N15N3GATMA1

Technical Details

• Series:OptiMOS™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):150 V
• Current - Continuous Drain (Id) @ 25°C:50A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):8V, 10V
• Rds On (Max) @ Id, Vgs:20mOhm @ 50A, 10V
• Vgs(th) (Max) @ Id:4V @ 90µA

• Gate Charge (Qg) (Max) @ Vgs:31 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:1820 pF @ 75 V
• FET Feature:-
• Power Dissipation (Max):150W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:D²PAK (TO-263AB)
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
