2SK3044

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):450 V
• Current - Continuous Drain (Id) @ 25°C:7A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:750mOhm @ 4A, 10V
• Vgs(th) (Max) @ Id:5V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:1300 pF @ 20 V
• FET Feature:-
• Power Dissipation (Max):2W (Ta), 40W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220D-A1
• Package / Case:TO-220-3 Full Pack
