PSMN8R0-30YLC,115
NXP Semiconductors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 54A LFPAK56
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:54A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:7.9mOhm @ 15A, 10V
- Vgs(th) (Max) @ Id:1.95V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:15 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:848 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):42W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:LFPAK56, Power-SO8
- Package / Case:SC-100, SOT-669
