RE1C002ZPMGTL

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:200mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.2V, 4.5V
• Rds On (Max) @ Id, Vgs:1.2Ohm @ 200mA, 4.5V
• Vgs(th) (Max) @ Id:1V @ 100µA

• Gate Charge (Qg) (Max) @ Vgs:1.4 nC @ 4.5 V
• Vgs (Max):±10V
• Input Capacitance (Ciss) (Max) @ Vds:115 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):150W (Ta)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:EMT3F (SOT-416FL)
• Package / Case:SC-89, SOT-490
