HS1MAL M3G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- Description75NS, 1A, 1000V, HIGH EFFICIENT
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 7,080
Can ship immediately
Pricing:
- 1$0.44
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):1000 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:1.7 V @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):75 ns
- Current - Reverse Leakage @ Vr:1 µA @ 1000 V
- Capacitance @ Vr, F:8pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-221AC, SMA Flat Leads
- Supplier Device Package:Thin SMA
- Operating Temperature - Junction:-55°C ~ 150°C
