LL101A-GS18
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 60V 30MA SOD80
- CategoryDiodes - Rectifiers - Single
- Datasheet LL101A-GS18 Datasheet
-
ECAD Model
- Share
In Stock: 6,138
Can ship immediately
Pricing:
- 1$0.35
- 10,000$0.05651
- 30,000$0.05343
- 50,000$0.05034
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):60 V
- Current - Average Rectified (Io):30mA
- Voltage - Forward (Vf) (Max) @ If:1 V @ 15 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):1 ns
- Current - Reverse Leakage @ Vr:200 nA @ 50 V
- Capacitance @ Vr, F:2pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-213AC, MINI-MELF, SOD-80
- Supplier Device Package:SOD-80 MiniMELF
- Operating Temperature - Junction:125°C (Max)
