BAT54XV2T1G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionRECTIFIER DIODE, SCHOTTKY, 0.2A,
- CategoryDiodes - Rectifiers - Single
- Datasheet BAT54XV2T1G Datasheet
-
ECAD Model
- Share
In Stock: 1,903,037
Can ship immediately
Pricing:
- 1$0.03
- 3,000$0.00521
- 6,000$0.00455
- 15,000$0.0039
- 30,000$0.00368
- 75,000$0.00346
- 150,000$0.00325
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):30 V
- Current - Average Rectified (Io):200mA (DC)
- Voltage - Forward (Vf) (Max) @ If:800 mV @ 100 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):5 ns
- Current - Reverse Leakage @ Vr:2 µA @ 25 V
- Capacitance @ Vr, F:10pF @ 1V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-79, SOD-523
- Supplier Device Package:SOD-523
- Operating Temperature - Junction:-55°C ~ 125°C
