STTH61W04SW
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 400V 60A TO247
- CategoryDiodes - Rectifiers - Single
- Datasheet STTH61W04SW Datasheet
-
ECAD Model
- Share
In Stock: 503
Can ship immediately
Pricing:
- 1$2.8
- 600$2.22869
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):400 V
- Current - Average Rectified (Io):60A
- Voltage - Forward (Vf) (Max) @ If:1.35 V @ 60 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):55 ns
- Current - Reverse Leakage @ Vr:20 µA @ 400 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:TO-247-3
- Supplier Device Package:TO-247
- Operating Temperature - Junction:175°C (Max)
