LD29300P2MTR
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR POS ADJ 3A P2PAK-4
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet LD29300P2MTR Datasheet
-
ECAD Model
- Share
In Stock: 20,382
Can ship immediately
Pricing:
- 1$1.21
- 1,000$0.45684
- 2,000$0.42639
- 5,000$0.40506
- 10,000$0.38984
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Output Configuration:Positive
- Output Type:Adjustable
- Number of Regulators:1
- Voltage - Input (Max):14V
- Voltage - Output (Min/Fixed):1.23V
- Voltage - Output (Max):13.3V
- Voltage Dropout (Max):0.7V @ 3A
- Current - Output:3A
- Current - Quiescent (Iq):50 mA
- Current - Supply (Max):100 mA
- PSRR:75dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
- Supplier Device Package:P2PAK-4
