LT3023EDD#PBF
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR POS ADJ 10DFN
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet LT3023EDD#PBF Datasheet
-
ECAD Model
- Share
In Stock: 549
Can ship immediately
Pricing:
- 1$4.55
- 25$3.02173
- 100$2.49864
- 250$2.37371
- 500$2.32017
- 5,000$2.23093
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Adjustable
- Number of Regulators:2
- Voltage - Input (Max):20V
- Voltage - Output (Min/Fixed):1.22V
- Voltage - Output (Max):20V
- Voltage Dropout (Max):0.45V @ 100mA, 0.45V @ 100mA
- Current - Output:100mA, 100mA
- Current - Quiescent (Iq):-
- Current - Supply (Max):-
- PSRR:65dB (120Hz)
- Control Features:Enable
- Protection Features:Over Current, Over Temperature, Reverse Polarity
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:10-WFDFN Exposed Pad
- Supplier Device Package:10-DFN (3x3)
