MAX8869EUE25+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR POS ADJ 1A 16TSSOP
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet MAX8869EUE25+ Datasheet
-
ECAD Model
- Share
In Stock: 374
Can ship immediately
Pricing:
- 1$5.74
- 10$5.15595
- 96$4.87397
- 192$4.22412
- 288$4.0075
- 576$3.59591
- 1,056$3.03269
- 2,592$2.88106
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Adjustable (Fixed)
- Number of Regulators:1
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):0.8V (2.5V)
- Voltage - Output (Max):5V
- Voltage Dropout (Max):-
- Current - Output:1A
- Current - Quiescent (Iq):2 mA
- Current - Supply (Max):2.5 mA
- PSRR:54dB (100kHz)
- Control Features:Enable, Reset, Soft Start
- Protection Features:Over Current, Over Temperature, Short Circuit
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package:16-TSSOP-EP
