LDL1117S15R
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 1.5V 1.2A SOT223
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet LDL1117S15R Datasheet
-
ECAD Model
- Share
In Stock: 7,125
Can ship immediately
Pricing:
- 1$0.38
- 2,500$0.08228
- 5,000$0.07729
- 12,500$0.07231
- 25,000$0.06632
- 62,500$0.06383
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):18V
- Voltage - Output (Min/Fixed):1.5V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.6V @ 1.2A
- Current - Output:1.2A
- Current - Quiescent (Iq):500 µA
- Current - Supply (Max):-
- PSRR:87dB ~ 65dB (120Hz ~ 100kHz)
- Control Features:-
- Protection Features:Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Operating Temperature:-40°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223
