UA78L09ACLPE3
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 9V 100MA TO92-3
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 4,004
Can ship immediately
Pricing:
- 1$0.48
- 10$0.40696
- 100$0.30386
- 500$0.23875
- 1,000$0.18449
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):24V
- Voltage - Output (Min/Fixed):9V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.7V @ 40mA
- Current - Output:100mA
- Current - Quiescent (Iq):-
- Current - Supply (Max):-
- PSRR:45dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Operating Temperature:0°C ~ 125°C
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-92-3
