ADP7156ACPZ-1.2-R7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 1.2V 1.2A 10LFCSP
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet ADP7156ACPZ-1.2-R7 Datasheet
-
ECAD Model
- Share
In Stock: 583
Can ship immediately
Pricing:
- 1$7.16
- 1,500$4.10147
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):1.2V
- Voltage - Output (Max):-
- Voltage Dropout (Max):-
- Current - Output:1.2A
- Current - Quiescent (Iq):8 mA
- Current - Supply (Max):12 mA
- PSRR:80dB ~ 60dB (1kHz ~ 1MHz)
- Control Features:Enable
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:10-VFDFN Exposed Pad, CSP
- Supplier Device Package:10-LFCSP (3x3)
