NCP1117ST33T3G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED POSITIVE LDO REGULATOR, 3.
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet NCP1117ST33T3G Datasheet
-
ECAD Model
- Share
In Stock: 111,745
Can ship immediately
Pricing:
- 1$0.14
- 4,000$0.05197
- 8,000$0.04862
- 12,000$0.04526
- 28,000$0.04292
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):20V
- Voltage - Output (Min/Fixed):3.3V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.2V @ 800mA
- Current - Output:1A
- Current - Quiescent (Iq):10 mA
- Current - Supply (Max):-
- PSRR:64dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:0°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223
