TLV1117-15CDCY
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LIN 1.5V 800MA SOT223-4
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 293
Can ship immediately
Pricing:
- 1$0.85
- 10$0.7446
- 80$0.69913
- 160$0.57063
- 560$0.45107
- 1,040$0.36085
- 2,560$0.32702
- 5,040$0.30447
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):15V
- Voltage - Output (Min/Fixed):1.5V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.3V @ 800mA
- Current - Output:800mA
- Current - Quiescent (Iq):10 mA
- Current - Supply (Max):-
- PSRR:75dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:0°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223-4
