MC7915BD2T
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR -15V 1A D2PAK
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet MC7915BD2T Datasheet
-
ECAD Model
- Share
In Stock: 546
Can ship immediately
Pricing:
- 1$0.44
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Output Configuration:Negative
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):-35V
- Voltage - Output (Min/Fixed):-15V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.3V @ 1A (Typ)
- Current - Output:1A
- Current - Quiescent (Iq):-
- Current - Supply (Max):-
- PSRR:60dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package:D2PAK
