MAX5086AATE+
Maxim Integrated
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LIN POS ADJ 250MA 16TQFN
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet MAX5086AATE+ Datasheet
-
ECAD Model
- Share
In Stock: 137
Can ship immediately
Pricing:
- 1$3.53
- 10$3.17351
- 60$3.0005
- 120$2.60043
- 300$2.46708
- 540$2.2137
- 1,020$1.86698
- 2,520$1.77363
- 5,040$1.70695
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Adjustable (Fixed)
- Number of Regulators:1
- Voltage - Input (Max):45V
- Voltage - Output (Min/Fixed):2.5V (3.3V)
- Voltage - Output (Max):11V
- Voltage Dropout (Max):-
- Current - Output:250mA
- Current - Quiescent (Iq):115 µA
- Current - Supply (Max):-
- PSRR:54dB (100Hz)
- Control Features:Enable, Reset
- Protection Features:Over Current, Over Temperature, Short Circuit
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:16-WQFN Exposed Pad
- Supplier Device Package:16-TQFN (5x5)
