TPS70151PWPG4
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 3.3V/1.8V 20HTSSOP
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$3.72057
- 140$3.69971
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:2
- Voltage - Input (Max):6V
- Voltage - Output (Min/Fixed):3.3V, 1.8V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.28V @ 500mA, -
- Current - Output:500mA, 250mA
- Current - Quiescent (Iq):190 µA
- Current - Supply (Max):230 µA
- PSRR:60dB (1kHz)
- Control Features:Enable, Power Good, Reset, Sequencing
- Protection Features:Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:20-PowerTSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-HTSSOP
