LM109K
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 5.05V 1A TO3-2
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 108
Can ship immediately
Pricing:
- 1$61.4326
- 50$40.51688
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):25V
- Voltage - Output (Min/Fixed):5.05V
- Voltage - Output (Max):-
- Voltage Dropout (Max):-
- Current - Output:1A
- Current - Quiescent (Iq):5.2 mA
- Current - Supply (Max):10 mA
- PSRR:-
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-55°C ~ 150°C
- Mounting Type:Through Hole
- Package / Case:TO-204AA, TO-3
- Supplier Device Package:TO-3-2
