AP1156ADS13
Asahi Kasei Microdevices / AKM Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LIN -1.3V 150MA SOT23-5
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet AP1156ADS13 Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Output Configuration:Negative
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):-17V
- Voltage - Output (Min/Fixed):-1.3V
- Voltage - Output (Max):-
- Voltage Dropout (Max):-
- Current - Output:150mA
- Current - Quiescent (Iq):300 µA
- Current - Supply (Max):-
- PSRR:-
- Control Features:Enable
- Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:SC-74A, SOT-753
- Supplier Device Package:SOT-23-5
