691304530008

Technical Details

• Series:WR-TBL Series 3045
• Package:Bulk
• Part Status:Active
• Type:Plug, Female Sockets
• Number of Positions:8
• Positions Per Level:8
• Number of Levels:1
• Pitch:0.200" (5.08mm)
• Header Orientation:-
• Plug Wire Entry:180°
• Termination Style:Screwless

• Mounting Type:Free Hanging (In-Line)
• Current - IEC:-
• Voltage - IEC:-
• Current - UL:16 A
• Voltage - UL:300 V
• Wire Gauge or Range - AWG:12-26 AWG
• Wire Gauge or Range - mm²:0.13-3.31mm²
• Color:Green
• Operating Temperature:-40°C ~ 105°C
• Contact Mating Finish:Tin
• Features:Latch Lock
