691307400004
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- Description7.62 MM TERMINAL BLOCK HEADER, V
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 325
Can ship immediately
Pricing:
- 1$4.04
Quote It
Technical Details
- Series:WR-TBL Series 3074
- Package:Bulk
- Part Status:Active
- Type:Header, Female Sockets
- Number of Positions:4
- Positions Per Level:4
- Number of Levels:1
- Pitch:0.300" (7.62mm)
- Header Orientation:Vertical
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:20 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Green
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:Tin
- Features:Retention Latches
