796605-3
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 3POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 796605-3 Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Buchanan
- Package:Bulk
- Part Status:Obsolete
- Type:Plug for Unshrouded Header
- Number of Positions:3
- Positions Per Level:3
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screw - Rising Cage Clamp
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:10 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:14-22 AWG
- Wire Gauge or Range - mm²:0.3-2mm²
- Color:Blue
- Operating Temperature:-55°C ~ 155°C
- Contact Mating Finish:Tin
- Features:Interlocking (Side)
