B32798G2756J

Technical Details

• Series:B32798
• Package:Bulk
• Part Status:Obsolete
• Capacitance:75 µF
• Tolerance:±5%
• Voltage Rating - AC:250V
• Voltage Rating - DC:630V
• Dielectric Material:Polypropylene (PP), Metallized
• ESR (Equivalent Series Resistance):2.1 mOhms
• Operating Temperature:-40°C ~ 85°C

• Mounting Type:Through Hole
• Package / Case:Radial - 4 Leads
• Size / Dimension:2.264" L x 1.378" W (57.50mm x 35.00mm)
• Height - Seated (Max):1.969" (50.00mm)
• Termination:PC Pins
• Lead Spacing:2.067" (52.50mm)
• Applications:DC Link, DC Filtering; EMI, RFI Suppression
• Ratings:-
• Features:-
