P6SMB16A-E3/52
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 13.6V 22.5V DO214AA
- CategoryTVS - Diodes
- Datasheet P6SMB16A-E3/52 Datasheet
-
ECAD Model
- Share
In Stock: 322
Can ship immediately
Pricing:
- 1$0.45
- 750$0.17413
- 1,500$0.13423
- 2,250$0.12425
- 5,250$0.11761
- 18,750$0.11096
- 37,500$0.1032
Quote It
Technical Details
- Series:P6SMB, TransZorb®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):13.6V
- Voltage - Breakdown (Min):15.2V
- Voltage - Clamping (Max) @ Ipp:22.5V
- Current - Peak Pulse (10/1000µs):26.7A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
