SMBJ75D-M3/H
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTVS DIODE 75V 119V DO214AA
- CategoryTVS - Diodes
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$0.48
- 750$0.17464
- 1,500$0.13747
- 2,250$0.12508
- 5,250$0.11888
- 18,750$0.10959
- 37,500$0.1034
Quote It
Technical Details
- Series:TransZorb®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Zener
- Unidirectional Channels:1
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):75V
- Voltage - Breakdown (Min):84.6V
- Voltage - Clamping (Max) @ Ipp:119V
- Current - Peak Pulse (10/1000µs):5.06A
- Power - Peak Pulse:600W
- Power Line Protection:No
- Applications:General Purpose
- Capacitance @ Frequency:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:DO-214AA (SMBJ)
