SZNSP8814MUTAG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- Description4 CHANNEL TVS ARRAY
- CategoryTVS - Diodes
- Datasheet SZNSP8814MUTAG Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)
- Part Status:Active
- Type:Steering (Rail to Rail)
- Unidirectional Channels:4
- Bidirectional Channels:-
- Voltage - Reverse Standoff (Typ):3V (Max)
- Voltage - Breakdown (Min):3.2V
- Voltage - Clamping (Max) @ Ipp:15V
- Current - Peak Pulse (10/1000µs):35A (8/20µs)
- Power - Peak Pulse:-
- Power Line Protection:No
- Applications:Automotive, Ethernet
- Capacitance @ Frequency:1.5pF @ 1MHz
- Operating Temperature:-55°C ~ 125°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:8-UDFN Exposed Pad
- Supplier Device Package:8-UDFN (2x2.2)
