09694117214
HARTING
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB PLUG 21POS SLDR CUP
- CategoryD-Sub Connectors
- Datasheet 09694117214 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$8.12
- 10$7.76696
- 25$7.06087
- 50$6.70783
- 100$6.5313
- 250$5.82522
- 500$5.47217
- 1,000$4.8367
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Connector Style:D-Sub, Combo
- Connector Type:Plug, Male Pins
- Number of Positions:21 (17 + 4 Coax or Power)
- Number of Rows:2
- Mounting Type:Free Hanging (In-Line)
- Shell Size, Connector Layout:4 (DC, C) - 21WA4
- Contact Type:Signal and Coax or Power (Not Included)
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:Solder Cup
- Shell Material, Finish:Steel, Tin Plated
- Contact Finish:-
- Contact Finish Thickness:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):5A
- Backset Spacing:-
- Features:Grounding Indents
