DB-25SF-N
JAE Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN D-SUB RCPT 25POS PNL MNT
- CategoryD-Sub Connectors
- Datasheet DB-25SF-N Datasheet
-
ECAD Model
- Share
In Stock: 151
Can ship immediately
Pricing:
- 1$5.712
- 720$5.712
Quote It
Technical Details
- Series:-
- Package:-
- Part Status:Active
- Connector Style:D-Sub
- Connector Type:Receptacle, Female Sockets
- Number of Positions:25
- Number of Rows:2
- Mounting Type:Panel Mount
- Shell Size, Connector Layout:3 (DB, B)
- Contact Type:Signal
- Flange Feature:Housing/Shell (Unthreaded)
- Termination:Solder Cup
- Shell Material, Finish:Steel, Nickel Plated
- Contact Finish:Gold
- Contact Finish Thickness:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Current Rating (Amps):5A
- Backset Spacing:-
- Features:Shielded
