LQW2UAS18NJ00L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 18NH 1A 110 MOHM SMD
- CategoryFixed Inductors
- Datasheet LQW2UAS18NJ00L Datasheet
-
ECAD Model
- Share
In Stock: 3,308
Can ship immediately
Pricing:
- 1$0.43
- 2,000$0.18394
- 4,000$0.17312
- 6,000$0.16771
- 10,000$0.1623
- 50,000$0.15148
Quote It
Technical Details
- Series:LQW2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Air
- Inductance:18 nH
- Tolerance:±5%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):110mOhm Max
- Q @ Freq:50 @ 350MHz
- Frequency - Self Resonant:2.5GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:50 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.103" L x 0.096" W (2.62mm x 2.45mm)
- Height - Seated (Max):0.080" (2.03mm)
