LMLP04A4N4R7CTAS
Elco (AVX)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 960MA 140 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 8,051
Can ship immediately
Pricing:
- 1$0.36
Quote It
Technical Details
- Series:LMLP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±30%
- Current Rating (Amps):960 mA
- Current - Saturation (Isat):1.05A
- Shielding:Shielded
- DC Resistance (DCR):140mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.047" (1.20mm)
