SPM10040XT-R47M
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 470NH 22A 1.32 MOHM
- CategoryFixed Inductors
- Datasheet SPM10040XT-R47M Datasheet
-
ECAD Model
- Share
In Stock: 1,478
Can ship immediately
Pricing:
- 1$1.4
- 500$0.72
- 1,000$0.64
- 2,500$0.62
- 5,000$0.6
- 12,500$0.58
Quote It
Technical Details
- Series:SPM
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:470 nH
- Tolerance:±20%
- Current Rating (Amps):22 A
- Current - Saturation (Isat):25A
- Shielding:Shielded
- DC Resistance (DCR):1.32mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD, J-Lead
- Supplier Device Package:-
- Size / Dimension:0.453" L x 0.394" W (11.50mm x 10.00mm)
- Height - Seated (Max):0.157" (4.00mm)
