#B966BS-270M=P3
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 27UH 2.3A 74 MOHM SMD
- CategoryFixed Inductors
- Datasheet #B966BS-270M=P3 Datasheet
-
ECAD Model
- Share
In Stock: 1,112
Can ship immediately
Pricing:
- 1$0.95
- 500$0.48888
- 1,000$0.43456
- 2,500$0.42098
- 5,000$0.4074
- 12,500$0.39382
- 25,000$0.38024
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:27 µH
- Tolerance:±20%
- Current Rating (Amps):2.3 A
- Current - Saturation (Isat):2.4A
- Shielding:Shielded
- DC Resistance (DCR):74mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.409" L x 0.409" W (10.40mm x 10.40mm)
- Height - Seated (Max):0.268" (6.80mm)
