HCTI-22-16.4
Signal Transformer
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 16.4A 7 MOHM TH
- CategoryFixed Inductors
- Datasheet HCTI-22-16.4 Datasheet
-
ECAD Model
- Share
In Stock: 766
Can ship immediately
Pricing:
- 1$2.31
- 10$2.13106
- 100$1.49196
- 500$1.20775
- 1,000$1.10118
- 2,500$1.06566
Quote It
Technical Details
- Series:HCTI
- Package:Tray
- Part Status:Active
- Type:Toroidal
- Material - Core:-
- Inductance:22 µH
- Tolerance:±15%
- Current Rating (Amps):16.4 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):7mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical (Open)
- Supplier Device Package:-
- Size / Dimension:1.280" Dia x 0.650" W (32.51mm x 16.51mm)
- Height - Seated (Max):-
