2105-V-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 7A 15 MOHM TH
- CategoryFixed Inductors
- Datasheet 2105-V-RC Datasheet
-
ECAD Model
- Share
In Stock: 398
Can ship immediately
Pricing:
- 1$2.92
- 10$2.69729
- 100$1.88835
- 500$1.52864
- 1,000$1.40698
Quote It
Technical Details
- Series:2100
- Package:Bulk
- Part Status:Active
- Type:Toroidal
- Material - Core:-
- Inductance:22 µH
- Tolerance:±15%
- Current Rating (Amps):7 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):15mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical (Open)
- Supplier Device Package:-
- Size / Dimension:0.860" Dia x 0.450" W (21.84mm x 11.43mm)
- Height - Seated (Max):-
