MPX1D1250L6R8
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 11.6A 15.5 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 210
Can ship immediately
Pricing:
- 1$3.16
Quote It
Technical Details
- Series:METCOM MPX
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal Composite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):11.6 A
- Current - Saturation (Isat):14A
- Shielding:Shielded
- DC Resistance (DCR):15.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.520" L x 0.492" W (13.20mm x 12.50mm)
- Height - Seated (Max):0.197" (5.00mm)
