74478612
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22NH 600MA 650 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 196
Can ship immediately
Pricing:
- 1$0.55
Quote It
Technical Details
- Series:WE-MK
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic
- Inductance:22 nH
- Tolerance:±5%
- Current Rating (Amps):600 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):650mOhm Max
- Q @ Freq:10 @ 100MHz
- Frequency - Self Resonant:2.1GHz
- Ratings:-
- Operating Temperature:-40°C ~ 120°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603
- Size / Dimension:0.063" L x 0.031" W (1.60mm x 0.80mm)
- Height - Seated (Max):0.037" (0.95mm)
