B82472D6103M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 2.3A 105 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$2.27
Quote It
Technical Details
- Series:B82472D6
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):2.3 A
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):105mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:4-SMD
- Size / Dimension:0.287" L x 0.287" W (7.30mm x 7.30mm)
- Height - Seated (Max):0.189" (4.80mm)
