L0603C3N3SRMST
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3NH 300MA 120 MOHM
- CategoryFixed Inductors
- Datasheet L0603C3N3SRMST Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$0.04896
- 4,000$0.04896
Quote It
Technical Details
- Series:L-RMS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic
- Inductance:3.3 nH
- Tolerance:±0.3nH
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:14 @ 100MHz
- Frequency - Self Resonant:9GHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.063" L x 0.032" W (1.60mm x 0.81mm)
- Height - Seated (Max):0.028" (0.71mm)
