IHSM7832ER102L
Vishay / Dale
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 510MA 2.42 OHM SMD
- CategoryFixed Inductors
- Datasheet IHSM7832ER102L Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$3.072
- 500$3.072
- 1,000$2.88
- 2,500$2.784
Quote It
Technical Details
- Series:IHSM-7832
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±15%
- Current Rating (Amps):510 mA
- Current - Saturation (Isat):210mA
- Shielding:Unshielded
- DC Resistance (DCR):2.42Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.840" L x 0.320" W (21.34mm x 8.13mm)
- Height - Seated (Max):0.285" (7.24mm)
