N08DPB561K

Technical Details

• Series:N
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Type:-
• Material - Core:-
• Inductance:560 µH
• Tolerance:±10%
• Current Rating (Amps):380 mA
• Current - Saturation (Isat):-
• Shielding:Unshielded
• DC Resistance (DCR):2.4Ohm Max

• Q @ Freq:-
• Frequency - Self Resonant:2.7MHz
• Ratings:-
• Operating Temperature:-25°C ~ 85°C
• Inductance Frequency - Test:1 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.417" L x 0.354" W (10.60mm x 9.00mm)
• Height - Seated (Max):0.197" (5.00mm)
