LDZ28176R8K-10
Laird - Performance Materials
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 26A 3 MOHM TH
- CategoryFixed Inductors
- Datasheet LDZ28176R8K-10 Datasheet
-
ECAD Model
- Share
In Stock: 159
Can ship immediately
Pricing:
- 1$7.55
- 10$6.794
- 100$4.8314
- 500$4.5294
- 1,000$4.22744
Quote It
Technical Details
- Series:LDZ2817
- Package:Tray
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±10%
- Current Rating (Amps):26 A
- Current - Saturation (Isat):56A
- Shielding:Shielded
- DC Resistance (DCR):3mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:300 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical, 4 Leads (Open)
- Supplier Device Package:-
- Size / Dimension:1.063" L x 0.669" W (27.00mm x 17.00mm)
- Height - Seated (Max):0.906" (23.00mm)
