B41231A7109M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 10000UF 20% 35V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet B41231A7109M000 Datasheet
-
ECAD Model
- Share
In Stock: 1,188
Can ship immediately
Pricing:
- 1$2.6
- 10$2.13865
- 100$1.67573
- 500$1.31914
- 1,000$1.17653
- 2,500$1.14087
- 5,000$1.10522
Quote It
Technical Details
- Series:B41231
- Package:Bulk
- Part Status:Active
- Capacitance:10000 µF
- Tolerance:±20%
- Voltage - Rated:35 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:4.68 A @ 120 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:0.394" (10.00mm)
- Size / Dimension:0.866" Dia (22.00mm)
- Height - Seated (Max):2.047" (52.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In
