860080773003
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 18UF 20% 63V THRU HOLE
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 1,583
Can ship immediately
Pricing:
- 1$0.16
- 1,500$0.09139
Quote It
Technical Details
- Series:WCAP-ATLI
- Package:Cut Tape (CT)Tape & Box (TB)
- Part Status:Active
- Capacitance:18 µF
- Tolerance:±20%
- Voltage - Rated:63 V
- ESR (Equivalent Series Resistance):-
- Lifetime @ Temp.:2000 Hrs @ 105°C
- Operating Temperature:-55°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:-
- Ripple Current @ High Frequency:170 mA @ 100 kHz
- Impedance:820 mOhms
- Lead Spacing:0.098" (2.50mm)
- Size / Dimension:0.248" Dia (6.30mm)
- Height - Seated (Max):0.492" (12.50mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can
