ECE-T2VP122EA
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1200UF 20% 350V SNAP
- CategoryAluminum Electrolytic Capacitors
- Datasheet ECE-T2VP122EA Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$8.83227
- 150$8.83227
Quote It
Technical Details
- Series:T-UP
- Package:Bulk
- Part Status:Active
- Capacitance:1200 µF
- Tolerance:±20%
- Voltage - Rated:350 V
- ESR (Equivalent Series Resistance):207mOhm @ 120Hz
- Lifetime @ Temp.:3000 Hrs @ 85°C
- Operating Temperature:-25°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:4.42 A @ 120 Hz
- Ripple Current @ High Frequency:6.188 A @ 10 kHz
- Impedance:-
- Lead Spacing:0.886" (22.50mm)
- Size / Dimension:1.378" Dia (35.00mm)
- Height - Seated (Max):3.150" (80.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In - 4 Lead
