MAL225917471E3

Technical Details

• Series:259 PHM-SI
• Package:Box
• Part Status:Active
• Capacitance:470 µF
• Tolerance:±20%
• Voltage - Rated:450 V
• ESR (Equivalent Series Resistance):280mOhm @ 100Hz
• Lifetime @ Temp.:3000 Hrs @ 105°C
• Operating Temperature:-40°C ~ 105°C
• Polarization:Polar
• Ratings:-

• Applications:General Purpose
• Ripple Current @ Low Frequency:2.36 A @ 100 Hz
• Ripple Current @ High Frequency:3.54 A @ 10 kHz
• Impedance:200 mOhms
• Lead Spacing:0.394" (10.00mm)
• Size / Dimension:1.378" Dia (35.00mm)
• Height - Seated (Max):2.047" (52.00mm)
• Surface Mount Land Size:-
• Mounting Type:Through Hole
• Package / Case:Radial, Can - Snap-In - 3 Lead
