MAL229966182E3
Vishay BC Components/Beyshlag/Draloric
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1800UF 400V 5000H
- CategoryAluminum Electrolytic Capacitors
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$35.475
Quote It
Technical Details
- Series:299 PHL-4TSI
- Package:Box
- Part Status:Active
- Capacitance:1800 µF
- Tolerance:±20%
- Voltage - Rated:400 V
- ESR (Equivalent Series Resistance):80mOhm @ 100Hz
- Lifetime @ Temp.:5000 Hrs @ 105°C
- Operating Temperature:-40°C ~ 105°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:5.74 A @ 100 Hz
- Ripple Current @ High Frequency:8.61 A @ 10 kHz
- Impedance:60 mOhms
- Lead Spacing:0.886" (22.50mm)
- Size / Dimension:1.772" Dia (45.00mm)
- Height - Seated (Max):3.228" (82.00mm)
- Surface Mount Land Size:-
- Mounting Type:Through Hole
- Package / Case:Radial, Can - Snap-In - 4 Lead
