ALS30A152NF500
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP ALUM 1500UF 20% 500V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet ALS30A152NF500 Datasheet
-
ECAD Model
- Share
In Stock: 152
Can ship immediately
Pricing:
- 1$45.84646
- 48$43.66313
Quote It
Technical Details
- Series:ALS30
- Package:Bulk
- Part Status:Active
- Capacitance:1500 µF
- Tolerance:±20%
- Voltage - Rated:500 V
- ESR (Equivalent Series Resistance):120mOhm @ 100Hz
- Lifetime @ Temp.:20000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:10.6 A @ 100 Hz
- Ripple Current @ High Frequency:17 A @ 10 kHz
- Impedance:65 mOhms
- Lead Spacing:1.252" (31.80mm)
- Size / Dimension:3.032" Dia (77.00mm)
- Height - Seated (Max):4.213" (107.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
