PEH200OV4330MB2
KEMET
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCAP 3300UF 420V SCREW
- CategoryAluminum Electrolytic Capacitors
- Datasheet PEH200OV4330MB2 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$53.99167
- 48$53.99167
Quote It
Technical Details
- Series:PEH200
- Package:Bulk
- Part Status:Active
- Capacitance:3300 µF
- Tolerance:±20%
- Voltage - Rated:420 V
- ESR (Equivalent Series Resistance):22mOhm @ 100Hz
- Lifetime @ Temp.:19000 Hrs @ 85°C
- Operating Temperature:-40°C ~ 85°C
- Polarization:Polar
- Ratings:-
- Applications:General Purpose
- Ripple Current @ Low Frequency:14 A @ 100 Hz
- Ripple Current @ High Frequency:-
- Impedance:-
- Lead Spacing:1.260" (32.00mm)
- Size / Dimension:3.016" Dia (76.60mm)
- Height - Seated (Max):5.787" (147.00mm)
- Surface Mount Land Size:-
- Mounting Type:Chassis Mount
- Package / Case:Radial, Can - Screw Terminals
